CONTROL PANELS

Venera 6 Gang Touch Switch Venera 2/3 Gang Touch Switch Venera 4 Gang Touch Switch
Touch Buttons 6 Gangs Touch Buttons 2/3 Gangs Touch Buttons 4 Touch Gangs
Backlit RGB LED Indicators Backlit RGB LED Indicators Backlight RGB Backlit Indicators
OPERATION OPERATION
OPERATION TIS BUS TIS Protocol Messages and TIS BUS TIS Protocol Messages and Commands TIS BUS TIS Protocol Messages & Commands
Commands
Upgrading By Rs485 Upgrading Kit Upgrading By Rs485 Upgrading Kit
Upgrading By Rs485 Upgrading Kit
INPUT Input Voltage 110-230VAC 50/60 Hz REACTION TIME Approx. 30ms
INPUT Input Voltage 110-230VAC 50/60 Hz
Number of Channels 2/3
MOUNTING Junction Box US, EU, IT, UK Standard Number of Channels 4
OUTPUT Nominal Voltage 110VAC / 230VAC 50/60 Hz
OUTPUT Nominal Voltage 110VAC / 230VAC 50/60 Hz
Nominal Current per Channel 8A / 230VAC
Nominal Current per Channel 2A / 230VAC
MOUNTING Junction Box US, EU, IT, UK Standard
MOUNTING Junction Box US, EU, IT, UK Standard

Titan - Titania 2.4” Touch Switch Titan - Titania 2 / 3 Gang Touch Switch Titan - Titania 4 Gang Touch Switch
Active Area 2.5” Active Area 2-3 buttons Active Area 4 Buttons
TOUCH TOUCH TOUCH
Touch Type Capacitive Touch Type Capacitive Touch Type Capacitive
Size 2.4” Single Press ON/OFF/Scene Single Press ON/OFF/Scene
Resolution 240x320 FUNCTIONS Long Press Adjust Lights Brightness FUNCTIONS Long Press Adjust Lights Brightness
LCD
Contrast 600 Double Click Extra Scene Double Click Extra Scene
Viewing Direction 120 Degree
Temp Sensor Resistive temp. sensor Temp. Sensor Resistive Temp. Sensor
INPUT INPUT
Temp Sensor Resistive Temp. Sensor Dry Inputs 2 Digital Inputs Dry Inputs 2 Digital Inputs
INPUT
Dry Inputs 2 Digital Inputs
OUTPUT Relay Switch 2-3 Relay Outputs 5A OUTPUT Relay Switch 4 Relay Outputs 2A
OUTPUT Model with Relay - 3R 3 Relay Outputs 5A
Titian UK Junction Box Titian UK Junction Box
MOUNTING MOUNTING
Titian UK Junction Box Titania US Junction Box Titania US Junction Box
MOUNTING
Titania US Junction Box
